Stonex | SKU: B10+150215

Stonex S990+ GNSS Receiver

Name: Stonex S990+ GNSS Receiver
Brand: Stonex
SKU: B10+150215
Price: 6995.0 USD
Availability: InStock

$6,995.00 ~~$9,480.00~~

Shipping calculated at checkout.

Available Options

Product variants

Stonex S990+ GNSS Receiver - Rover is backordered. Expect an additional 3-5 days of shipping

Delivery and Shipping

Your order will be shipped out within 24 hours of purchase

A UPS tracking # will be provided via email and/or text when we create the label

Price Matching

Found a better price?

Send us an email with a link to the authorized dealers listing and we'll match it or do better!

info@aaisurvey.com

Speak With an Expert:

+1 (800) 821-9656
info@aaisurvey.com
Monday - Friday 9am-5pm PST

All Equipment Will Ship Calibrated

Optical Instruments & Rotating Lasers Come With A Certification

Description

The Stonex S990+ GNSS Receiver is a high-performance device designed to enhance field survey efficiency and accuracy. With 1408 channels, it supports all major satellite constellations, including GPS, GLONASS, BEIDOU, GALILEO, and QZSS, providing reliable real-time navigation solutions.

Equipped with an IMU system, the S990+ allows for tilted measurements up to 60°, facilitating rapid initialization and precise data collection even in challenging terrains. Its comprehensive connectivity suite includes Bluetooth, Wi-Fi, UHF radio, and a 4G modem, ensuring seamless data transmission and integration with various devices.

The receiver features an internal 10,200mAh battery, delivering up to 12 hours of continuous operation and can be conveniently recharged via a USB Type-C connector. The color touch display and Web UI offer intuitive control and management of the device's functions. Additionally, the 1PPS port provides precise timing capabilities, essential for applications requiring synchronized operations across multiple systems.

Key Features:

1408-channel GNSS receiver supporting GPS, GLONASS, BEIDOU, GALILEO, and QZSS
IMU technology enabling measurements with up to 60° tilt
Integrated connectivity: Bluetooth, Wi-Fi, UHF radio, and 4G modem
Long-lasting 10,200mAh battery with up to 12 hours of operation
User-friendly color touch display and Web UI for easy control
1PPS port for precise timing applications

What's Included

Rover Kit

(1) Stonex S990+ GNSS Receiver – B10+150215
(1) S990+ UHF Firmware Activation – 40-450224

Items Included in S990+ Box:

(1) S990+ Instrument Unit
(1) Power Adapter with 4 Plugs (US, UK, EU, AU) – 30-350292
(1) USB Type-C Charging Cable – 30-350293
(1) USB-A to USB-C Data Cable – 30-350300
(1) Measuring Tape (3m, MT-300) – 30-350063
(1) Carrying Case for S990 (CC-990) – 30-350336
(1) SW Cube-Link Software

Additional Included Accessories:

(1) PG-260 GNSS Pole (2.60m, 2-Section, Carbon Fiber/Aluminum, Telescopic) – 30-350607
(1) UHF Antenna, 450MHz-470MHz, TNC, 29cm (AR-430) – 30-350085
(1) Soft Cover for GNSS Carrying Case (SC-100) – 30-350608

Base & Rover Kit

(2) Stonex S990+ GNSS Receivers – B10+150215
(2) S990+ UHF Firmware Activations – 40-450224

Items Included in Each S990+ Box:

(2) S990+ Instrument Units
(2) Power Adapters with 4 Plugs (US, UK, EU, AU) – 30-350292
(2) USB Type-C Charging Cables – 30-350293
(2) USB-A to USB-C Data Cables – 30-350300
(2) Measuring Tapes (3m, MT-300) – 30-350063
(2) Carrying Cases for S990 (CC-990) – 30-350336
(2) SW Cube-Link Software

Additional Included Accessories:

Tripod, Aluminum, Twist Clamp, 1.60m (TA-160) – 30-000018
PG-260 GNSS Pole (2.60m, 2-Section, Carbon Fiber/Aluminum, Telescopic) – 30-350607
STJ13-S93B Tribrach (Metal, Three-Jaw, Without Optical Plummet, Black) – 30-350060
STL10-S93B Tribrach Adapter (Metal, Three-Jaw, Optical Plummet, Black) – 30-350061
Tribrach Adapter 5/8" – 30-350062
Glass Fiber Mounting Pole, 25cm (GF-025) – 30-350177
Height Measuring Plate for GNSS (HM-100) – 30-350176
(2) Soft Covers for GNSS Carrying Cases (SC-100) – 30-350608
(2) UHF Antennas, 450MHz-470MHz, TNC, 29cm (AR-430) – 30-350085
UHF Antenna Kit (AR-600) – 30-350341
