Leica CC200 Data Collector - Windows 11 Tablet with 10” Screen

Data Sheet

Overview

The Leica CC200 Data Collector is Leica’s high-performance 10-inch Windows 11 field tablet built for demanding surveying, construction layout, and field data collection workflows. Designed for users who need more screen space, more processing power, and a full Windows environment in the field, the CC200 is ideal for running Leica Captivate on larger projects with complex maps, surfaces, drawings, and design files.

Powered by an Intel Core Ultra5 processor with 16 GB RAM and 512 GB storage, the CC200 gives crews the speed and storage capacity needed for advanced field work. Its large anti-reflective 10-inch display provides excellent visibility for viewing points, linework, CAD data, maps, and project files clearly in the field.

What’s Included

• CC200-11-Cap Tablet, Windows 11, US/CA/MX (p/n: 1018502)

• CBC14 AC Power Supply (p/n: 972101)
• CA36 Power Cord, US, for AC/DC Adapter (p/n: 834380)
• Leica Entitlement Activation Guide, English (p/n: 947231)

Optional Accessories

Additional accessories are available for the Leica CC200 to help customize the tablet for your field workflow, vehicle setup, or pole-mounted surveying configuration. If you would like to add any of these accessories to your order, please reach out to us, and we can help quote the correct items.

• CBA4 Large Battery for CC200 (p/n: 972099)
• CBC15 External 4-Bay Charger (p/n: 972102)
• CCA17 Vehicle Adapter for CC200 (p/n: 972103)
• CBC16 Docking Station for CC200 (p/n: 972104)
• Hand Strap (p/n: 972106)
• Protective Film (p/n: 972108)
• IP55 Digitizer Pen (p/n: 972110)
• GHT63 Pole Clamp Attachment GHT (p/n: 767880)
• GHT91 Holder for CC200 (p/n: 1018165)
• GHT92 Cradle for GKP100 (p/n: 1008402)
• GHT93 Add-on for GHT92 to CMB16 (p/n: 1014801)
• GKP100 Leica Captivate Keypad (p/n: 995129)

These accessories are useful for crews who want longer runtime, extra charging capacity, vehicle power, pole mounting, added screen protection, or a full keypad workflow with Leica Captivate.

Key Features

• Part Number: 1018572
• 10-inch rugged Windows field tablet
• Microsoft Windows 11 IoT Enterprise LTSC 2024
• Intel Core Ultra5 processor 135U
• 16 GB RAM
• 512 GB data storage
• 1920 × 1200 anti-reflective display
• Day/night display mode
• Touchscreen and digitizer pen support
• Finger, glove, and water touchscreen modes
• 4G LTE with nanoSIM/eSIM support
• Wi-Fi 6E and Bluetooth 5.3
• USB-C, USB-A, LAN, and DC-in ports
• 2 MP front camera
• 13 MP rear camera with autofocus and flash
• Battery life up to 12 hours on desk
• TPS working range up to 450 m
• IP6x/IPx5 dust and water resistance
• 1.8 m drop rating
• Operating temperature from -29°C to 60°C

Built for Leica Captivate Workflows

The Leica CC200 is designed for survey professionals who want the full power of a large-format Windows tablet in the field. Compared to smaller data collectors, the 10-inch screen makes it easier to view complex data, check linework, manage stakeout files, and work with larger project maps.

This makes the CC200 a strong choice for:

• Robotic total station work
• GNSS surveying
• Construction layout
• Topographic surveys
• Large design files
• Road and site projects
• As-built collection
• Field-to-office workflows

The larger display is especially useful when working with dense point files, surfaces, CAD drawings, and visual project data.

Compatible Software

The Leica CC200 works seamlessly with Leica Captivate, providing survey crews with a powerful Windows-based platform for robotic total station, GNSS, stakeout, measurement, coding, and data collection workflows. It is built for users who want a larger screen and higher performance than a traditional handheld controller.

When paired with Leica Captivate and Leica field instruments, the CC200 helps crews manage points, linework, surfaces, design files, and measured data directly in the field. It is well-suited for Leica robotic total stations, manual total stations, GNSS receivers, and construction positioning workflows.

The Windows 11 operating system also gives crews more flexibility for file handling, field utilities, data transfer, and office-style workflows directly on the controller.

Large 10-Inch Display for Field Visibility

The CC200 features a 10-inch, 1920 × 1200 anti-reflective touchscreen designed for outdoor use. The display supports day/night mode, digitizer pen input, 10-finger multitouch, and touchscreen modes for finger, glove, and wet conditions.

This makes it easier to work in bright sunlight, harsh lighting, wet conditions, or jobsite environments where standard tablets can be difficult to use.

Rugged Performance for Demanding Field Work

The CC200 is built to handle real survey and construction environments. With IP6x/IPx5 dust and water resistance, a 1.8 m drop rating, MIL-STD-810H testing, and an operating temperature range from -29°C to 60°C, it is designed for tough field conditions.

At 1.3 kg (2.90 lb), it provides a large screen and powerful hardware while remaining practical for field use.

Power, Connectivity, and Data Management

The Leica CC200 includes a high-capacity Li-Ion battery rated for up to 12 hours on desk, or up to 9 hours connected to GS / 6 hours with SIM usage on tablet, depending on workflow. It also includes 4G LTE, Wi-Fi 6E, Bluetooth 5.3, nanoSIM/eSIM support, and multiple ports for connecting field accessories and transferring data.

With USB-C, USB-A, LAN, and DC-in connectivity, the CC200 provides the ports professionals need for field and office integration.

Built for Professionals Who Need More Screen and More Power

The Leica CC200 Data Collector is the best choice for Leica users who want maximum tablet performance in the field. With a 10-inch anti-reflective display, Windows 11, 16 GB RAM, 512 GB storage, rugged environmental protection, and Leica Captivate compatibility, the CC200 gives survey and construction crews the speed, visibility, and flexibility needed for demanding projects.
