Leica Rugby 60DG Dual Grade Laser Level

Data Sheet - User Manual

What’s Included

The Leica Rugby 60DG is available in two complete packages. Both configurations include the Rugby 60DG laser, Rod Eye 105B digital receiver, and RC60 remote control. The primary difference is the battery system.

Alkaline Battery Package — Part No. 6020270

Leica 6020270 Rugby 60DG w/ RE105B, RC60, Alkaline includes:

• 1× Leica Rugby 60DG Laser with Carrying Case — Part No. 1051248
• 1× Leica Rod Eye 105B Digital Laser Receiver with Bracket — Part No. 1051251
• 1× Leica RC60 Remote Control for Rugby 60DG — Part No. 1051387
• 1× Alkaline Battery Tray for Rugby DG Lasers — Part No. 835250
• 2× D-Cell Alkaline Batteries, LR20 1.5V — Part No. 731957

Li-Ion Battery Package — Part No. 6020269

Leica 6020269 Rugby 60DG w/ RE105B, RC60, Li-Ion includes:

• 1× Leica Rugby 60DG Laser with Carrying Case — Part No. 1051248
• 1× Leica Rod Eye 105B Digital Laser Receiver with Bracket — Part No. 1051251
• 1× Leica RC60 Remote Control for Rugby 60DG — Part No. 1051387
• 1× Li-Ion Battery for Rugby DG Lasers — Part No. 835243
• 1× Leica A100 Li-Ion Charger — Part No. 790417

Overview

The Leica Rugby 60DG Dual Grade Laser Level is a fully automatic professional grade laser designed for construction crews that need accurate elevation and grade control across demanding jobsites. Digital grade can be entered on both axes up to 15%, allowing the Rugby 60DG to handle level, single-grade, and dual-grade applications with fast, repeatable setup.

With an operating diameter of up to 3,000 ft, accuracy of ±1/16 in at 100 ft, automatic self-leveling, and an IP67-rated housing, the Rugby 60DG is built for everyday grading, excavation, drainage, concrete, roadwork, and general site construction.

Key Features

• Fully Automatic Dual Grade: Digital grade control on both X and Y axes
• Up to 15% Grade: Handles a wide variety of construction grading applications
• 3,000 ft Operating Diameter: Covers large jobsites from a single setup
• ±1/16 in Accuracy at 100 ft: Professional-grade elevation control
• ±5° Self-Leveling Range: Automatically establishes an accurate laser plane
• 300, 600 & 900 RPM: Multiple rotation speeds for different jobsite applications
• Rod Eye 105B Included: Digital receiver with beam catching and beam lock
• RC60 Remote Included: Control the Rugby 60DG from up to 1,000 ft away
• Alkaline or Li-Ion Packages: Choose the power system that best fits your workflow
• IP67 Protection: Designed for demanding outdoor construction environments

Fully Automatic Dual Grade Control

The Rugby 60DG provides fully automatic digital grade control in both axes. Operators can enter the required grade directly into the laser, making it easy to establish precise grades without relying on manual laser head adjustments.

The system can be used for:

• Horizontal leveling
• Single-grade applications
• Dual-grade applications
• Vertical alignment
• Batter board work

With a grade range of up to 15%, the Rugby 60DG is suitable for everything from subtle drainage requirements to more aggressive site grading applications.

3,000 ft Long-Range Performance

The Leica Rugby 60DG has an operating range of up to 900 m / 3,000 ft diameter, giving contractors the ability to work across large construction sites without constantly relocating the laser.

Leica specifies accuracy at:

±1.5 mm at 30 m / ±1/16 in at 100 ft

This combination of range and accuracy makes the Rugby 60DG well suited for grading, excavation, concrete, foundations, drainage, road construction, and other applications where maintaining consistent elevations and grades over long distances is critical.

Leica Rod Eye 105B Digital Receiver

Both Rugby 60DG packages include the Leica Rod Eye 105B Digital Laser Receiver with Bracket.

The Rod Eye 105B provides:

• 3,000 ft / 900 m operating diameter
• 4 in / 105 mm detection window
• 3.5 in / 90 mm numeric readout height
• Beam Catching
• Beam Lock

Beam Catching

Beam Catching allows the Rugby 60DG to automatically locate the Rod Eye 105B receiver, helping crews establish the required grade plane faster without repeatedly returning to the laser.

Beam Lock

Beam Lock allows the system to monitor the receiver position and maintain alignment, helping provide dependable grade control during demanding applications.

Leica designed the Rugby 60DG and Rod Eye 105B combination to deliver repeatable, accurate results over long distances and in tough construction conditions.

Leica RC60 Remote Control

The included Leica RC60 Remote Control allows operators to control the Rugby 60DG without returning to the instrument for every adjustment.

The RC60 provides:

• 300 m / 1,000 ft operating radius
• Two AA battery power
• Approximately 70 hours of typical battery life

Remote operation is particularly useful during grade setup and alignment when the operator may be positioned hundreds of feet away from the laser.

Alkaline vs. Li-Ion Rugby 60DG Packages

Both Rugby 60DG packages provide the same dual-grade performance, Rod Eye 105B receiver, and RC60 remote. The difference is how the laser is powered.

6020270 — Alkaline Package

The 6020270 configuration includes Leica’s alkaline battery tray and two D-cell alkaline batteries.

The Rugby 60DG provides more than 60 hours of operating time on alkaline batteries, making this configuration a practical choice for crews that prefer readily available disposable batteries.

6020269 — Li-Ion Package

The 6020269 configuration includes a rechargeable Li-Ion battery and Leica A100 charger.

The rechargeable Li-Ion battery provides more than 40 hours of operating time per charge.

The Li-Ion package is ideal for crews that use the Rugby 60DG regularly and prefer a rechargeable power system rather than purchasing replacement D-cell batteries.

Built for Construction Environments

The Leica Rugby 60DG is designed for demanding outdoor use and carries an IP67 protection rating.

This rugged construction makes the Rugby 60DG suitable for year-round use on active construction sites where dust, dirt, moisture, and changing weather conditions are common.

Ideal Applications

The Leica Rugby 60DG is an excellent choice for:

• Site grading
• Excavation
• Drainage and sewer work
• Parking lots
• Road construction
• Foundations and footings
• Concrete forming
• Elevation control
• Landscaping
• Earthmoving
• Single-grade applications
• Dual-grade applications
• Batter boards
• Vertical alignment

Leica specifically designed the Rugby 60DG for level, single-grade, dual-grade, and batterboard applications where dependable accuracy must be maintained over long working distances.

Technical Specifications

Absolute Accuracy Dealer Support

When you purchase your Leica Rugby 60DG from Absolute Accuracy, our support doesn’t stop when the laser leaves the store. We can help you select the right battery configuration, tripod, grade rod, receiver accessories, and other equipment needed to build a complete setup for your application.

Our team is also available to assist with setup, operation, troubleshooting, accessory compatibility, calibration, service, and warranty coordination. Whether you are replacing an older construction laser or outfitting an entire crew, Absolute Accuracy can help make sure your Leica equipment is properly configured and ready for the jobsite.

Professional Dual Grade Control from Leica

The Leica Rugby 60DG Dual Grade Laser Level combines fully automatic dual-axis grade control, a 15% grade range, 3,000 ft working diameter, professional accuracy, beam catching, beam lock, and rugged IP67 construction into one complete grade laser system.

Choose the 6020270 Alkaline Package for the convenience and long runtime of readily available D-cell batteries, or the 6020269 Li-Ion Package for rechargeable everyday operation.
