SECO 5200-45 Claw Cradle Assembly for TSC7, Ranger 7, TSC3 and Ranger 3

Overview

The SECO 5200-45 Claw Cradle Assembly is a heavy-duty controller mounting system designed for the Trimble TSC7, Spectra Geospatial Ranger 7, Trimble TSC3, and Spectra Geospatial Ranger 3.

The updated Claw design combines a controller-specific cradle with a reinforced Quick-Release pole clamp. It keeps compatible data collectors securely mounted while providing six display positions ranging from vertical to horizontal.

Constructed from machine-anodized aluminum and stainless steel, the assembly is built for demanding survey and construction environments. Replaceable silicone pads grip the controller securely while helping protect its exterior from hard mounting surfaces.

Key Features

• Heavy-duty controller cradle and pole-clamp assembly
• SECO part number: 5200-45
• Designed for the Trimble TSC7
• Designed for the Spectra Geospatial Ranger 7
• Also compatible with the Trimble TSC3
• Also compatible with the Spectra Geospatial Ranger 3
• Six display tilt positions
• Adjusts from vertical to horizontal
• Reinforced SECO Quick-Release connection
• Uses the stronger Quick Release found on SECO heavy tablet brackets
• Fits standard 1.25-inch-diameter poles
• Machine-anodized aluminum construction
• Stainless-steel components
• Replaceable silicone controller pads
• Helps hold the controller securely without damaging it
• Complete assembly weighs 0.95 lb (0.43 kg)
• Includes cradle component 5200-079
• Includes pole-clamp component 5200-167

TSC7 and Ranger 7 Controller Mounting

The SECO 5200-45 features an updated Claw cradle design developed for the larger Trimble TSC7 and Spectra Geospatial Ranger 7 controllers.

Its dedicated cradle provides a secure fit while keeping the display, keypad, and controls accessible during GNSS surveying, robotic total station operation, and construction layout.

The heavy-duty design is suited for crews who regularly operate larger controllers from a rover rod or survey pole.

TSC3 and Ranger 3 Compatibility

The assembly is also compatible with the Trimble TSC3 and Spectra Geospatial Ranger 3.

For users of these controllers, the SECO 5200-45 provides a heavier-duty alternative with a stronger Quick-Release system and more display-angle positions than many standard controller brackets.

This can be especially useful when operators want additional flexibility in how the controller is positioned on the pole.

Six Display Positions

The pole clamp provides six fixed tilt positions ranging from vertical to horizontal.

These positions allow the controller display to be adjusted for different working conditions, including:

• Walking between survey points
• Viewing measurements while holding the pole
• Entering stakeout data
• Operating a robotic total station
• Reviewing maps and plans
• Working from a stationary rover setup

The multiple positions help operators set the display at a comfortable viewing and data-entry angle.

Heavy-Duty Quick-Release System

The SECO 5200-45 uses the stronger Quick-Release design found on SECO’s heavy tablet pole brackets.

The Quick-Release connection allows the controller cradle to be attached or removed from the pole clamp without taking the entire clamp off the pole. This makes it easier to move the controller between field use, charging, transportation, and secure storage.

The reinforced interface is designed to support the larger size and weight of compatible TSC7 and Ranger 7 controllers.

Replaceable Silicone Pads

Replaceable silicone pads contact the controller and help hold it securely inside the cradle.

The pads provide grip while helping protect the controller from scratches and hard contact with the aluminum cradle. Because the pads are replaceable, worn components can be serviced without replacing the complete mounting assembly.

Claw Pole-Clamping Design

The Claw system is designed to keep expensive data-collection hardware securely mounted while helping prevent excessive pressure from damaging the pole.

The pole clamp fits standard poles with a 1.25-inch outside diameter, commonly used for:

• GNSS rover rods
• Prism poles
• Survey poles
• Antenna poles
• Robotic surveying setups

Always confirm the outside diameter of the intended pole before ordering.

Anodized Aluminum and Stainless-Steel Construction

The cradle assembly is constructed from machine-anodized aluminum and stainless steel.

The aluminum components provide strength while keeping the system relatively lightweight. Stainless-steel hardware adds durability and corrosion resistance in areas exposed to repeated adjustment and field use.

The complete assembly weighs only 0.95 lb (0.43 kg).

Assembly Components

The SECO 5200-45 combines two primary components:

• SECO 5200-079 Claw Cradle
• SECO 5200-167 Pole Clamp

The cradle weighs 0.4 lb (0.18 kg), while the pole clamp weighs 0.55 lb (0.25 kg).

Together, they create a complete Quick-Release controller mounting system for compatible 1.25-inch poles.

Ideal Applications

• GNSS rover surveying
• Robotic total station operation
• Construction layout
• Survey stakeout
• Boundary surveying
• Topographic surveying
• Utility mapping
• GIS data collection
• Engineering fieldwork
• TSC7 and Ranger 7 pole mounting
• TSC3 and Ranger 3 pole mounting

Technical Specifications

What’s Included

• 1 × SECO Claw Cradle Assembly
• SECO p/n: 5200-45
• 1 × SECO Claw Controller Cradle
• Cradle p/n: 5200-079
• 1 × SECO Quick-Release Pole Clamp
• Pole clamp p/n: 5200-167
• Replaceable silicone controller pads

Controller, survey pole, GNSS receiver, prism, and other field equipment are sold separately.

Heavy-Duty Controller Mounting with Flexible Positioning

The SECO 5200-45 combines a reinforced Quick-Release interface, six tilt positions, replaceable silicone pads, and durable aluminum and stainless-steel construction. Its compatibility with the TSC7, Ranger 7, TSC3, and Ranger 3 makes it a versatile controller mount for professional surveying and construction layout.
