Sokkia iM-50 Total Station | 2" - 5"

Data Sheet

Overview

The Sokkia iM-50 Total Station is a reliable and easy-to-use instrument designed for construction layout, surveying, and general site measurement. Built with Sokkia’s trusted EDM technology, the iM-50 delivers fast and accurate measurements while maintaining the durability professionals expect in demanding field environments.

The instrument can measure reflectorless distances up to 500 m (1640 ft) and up to 4,000 m (13,123 ft) with a standard prism. This measurement capability makes it ideal for a wide range of tasks, including construction layout, topographic surveys, and general site verification.

Known for its rugged construction and straightforward onboard software, the iM-50 provides a practical solution for survey crews that need dependable performance without unnecessary complexity.

Built for Construction and Survey Work

The iM-50 series is designed to perform reliably across a wide range of surveying and construction applications. Its intuitive interface and durable construction allow crews to operate efficiently whether working on small layout jobs or large construction sites.

Typical applications include:

• Construction layout and staking
• Boundary and land surveying
• Topographic data collection
• As-built verification
• Utility and infrastructure mapping

The onboard software allows users to collect, store, and manage field data directly within the instrument, helping crews work efficiently without requiring additional hardware for basic measurement tasks.

Key Features

• Reflectorless measurement up to 500 m (1640 ft)
• Prism measurement range up to 4,000 m (13,123 ft)
• Angle accuracy options of 2″ or 5″
• Rugged IP66 dustproof and waterproof construction
• Large internal memory capable of storing up to 50,000 points
• USB support for external data storage
• Long battery runtime for full-day field operation
• Fast and accurate EDM measurement technology

These features make the iM-50 a dependable total station for professionals who need consistent performance in real-world field conditions.

Bluetooth Connectivity (Laser Plummet Models Only)

Certain versions of the Sokkia iM-50 include built-in Bluetooth connectivity for wireless communication with external data collectors and field software.

Bluetooth capability is only available on laser plummet models. Optical plummet versions of the iM-50 do not include Bluetooth functionality.

This wireless connection allows crews to control the total station and collect data using a compatible field controller without needing a physical cable connection.

Software Compatibility

The Sokkia iM-50 Total Station integrates with many of the most widely used surveying and construction field software platforms. Using standard Topcon and Sokkia communication protocols, the instrument can connect to external data collectors through serial cable or Bluetooth on laser plummet models.

This allows survey crews to operate the instrument using the software they already use for construction layout, topographic data collection, and survey workflows.

Compatible field software includes:

• Topcon Field / MAGNET Field
• Carlson SurvPC
• Carlson SurvCE
• MicroSurvey FieldGenius
• Leica Captivate (manual total station workflows)
• Trimble Access using generic total station drivers
• MAGNET Field Layout
• Pocket 3D for construction layout workflows

Because the iM-50 communicates using standard surveying protocols, it can also work with many additional third-party data collection platforms that support Topcon or Sokkia total stations.

Rugged Design Built for the Field

The iM-50 series is engineered to handle tough jobsite conditions. With its durable metal housing and IP66 environmental protection rating, the instrument is resistant to dust, water, and challenging outdoor environments.

It is designed to operate in temperatures ranging from -20°C to 60°C, allowing crews to work confidently in a wide range of climates and field conditions.

This durability ensures reliable performance for construction contractors, surveyors, and engineering professionals who depend on their equipment every day.

What’s Included

• Hard Case
• Topcon / Sokkia CDC77 Dual Battery Charger For BDC71 & BDC72 Batteries - 1038707-01
• EDC113B Charger Cable - 210160124
• Topcon / Sokkia BDC71 Li-Ion Battery - 1038705-01-SURSK
• Lens Brush
• Shoulder Strap / Belt
• Tool Pouch
• Screwdriver
• Lens Cap
• Adjusting Pin (2)
• Hexagonal Wrench
• Silicon Cloth
• Sun Shade / Lens Hood
